Details
Features:
- Standard keys are included
- Satin Chrome
- Athens (ATH) lever
- pressure cast zinc lever: wrought brass rose construction material
- ANSI: D12DEU
- Strike 1-1/4" x 4-7/8" ANSI type
- Electrically unlocked (Fail Secure): Auxiliary latch deadlocks the latchbolt when the door is closed
- The outside lever is continuously locked until it is unlocked by key or electric current
- The inside lever is always free for immediate egress
- UL-listed hardware for up to three-hour fire door
- Keyed functions of lever designs are field reversible
Specifications:
| Lever/Knob Design | Athens |
| Rose/Escutcheon Design | 3-7/16" Diameter |
| Cylinder Type | Conventional Cylinder |
| Number of Pins | 6 |
| Keying | Keyed Different |
| Number of keys | 2 |
| Door Thickness | 1-3/4" to 2." |
| latch type | Guarded latch |
| Latch backset | 2-3/4" |
| Lock Face Size | 2-1/4" X 1-1/8" |
| Strike Number | 10-025 |
| Strike Type | ASA |
| Strike Height | 4-7/8" |
| Strike Width | 1-1/4" |
| Dust Box | None |
| Screws | Combination |
| power | Hard Wired |
| Operating Voltage | 12VDC/24VDC |
| Amp Draw | 0.23 |
| Switch Type | None |
| Product Type | Electric Cylindrical Lock |
