Details
Flat | Cruciform Key Station
- Decoding via optical reader
- Copy by code and by original
- Four-sided rotating clamp
- Long-life WIDIA cutter
- Gauge for precise key installation
Laser | Dimple Cutting Station
- Decoding by electrical contact
- Easy-to-install clamp
- Interchangeable jaws
- Automatic calibration of the decoder and cutting station
- Pull-out tracer point
Specifications:
Technical Data:
| Machine | 24V d.c - 5.5 Amp - 130W |
| Power Pack | 90/264V a.c - 50/60Hz - 220W |
Cutter Motor:
| Flat Cuts | 24V d.c. |
Axes Run:
| Y Axis | 30 mm |
| X Axis | 50 mm |
| Z Axis | 27 mm |
Movements:
| Movements | Movement on 3 axes (with special bushes), driven by step motors on recitified roller guides |
Flat Cuts:
| Prismatic Cutter | U01W, hard Metal with coating |
| Clamp | 01V | Removable | Four universal sides holding flat, vehicle, and cruciform keys |
Dimple Cuts:
| Cutter | 01D, in HSS Super Rapid Steel |
| Clamp | 01R | Removable | Provided with interchangeable jaws |
Laser Cuts:
| Cutter | 01LW, in Carbide AICrN Coated |
| Clamp | 01R | Removable | Provided with interchangeable jaws |
Dimensions:
| Width | 318 mm |
| Depth | 413 mm |
| Height with Tablet and Stand | 530 mm |
| Height with Display Closed | 365 mm |
| Weight | 20 kg | 44.09 lbs |
Downloads:
Specifications
Remote Specifications
- Part Number
- M400, D8B0320ZM400
Notes
Ilco Key Cutting and Programming Machines are made for use in the North Amercian (U.S.A., Canada, Caribbean Islands) and Carribean Regions (Mexico, Guatemala, Belize, El Salvador, Honduras, Nicaragua, Costa Rica, Panama ). They are not intended to be used outside these regions and some models may have region locks on certain software functions and hardware may not be compatible with regional infrastructure. If you intend to purchase this for use outside of the specified regions you do so at your own risk. The manufacturer will refuse the warranty claims and may refuse software support if it is determined being used outside of the designated region. UHS Hardware has the right to refuse sale of this product outside its designated region
