EoneBoss - TLK2 - Toyota / Lexus 4A-AA BA Smart Key Unlock Tool

EoneBoss - TLK2 - Toyota / Lexus 4A-AA BA Smart Key Unlock Tool

In stock
SKU EOB-TLK2 NSID 95657
$59.95$71.94On Sale You save $11.99 (17%)
Get it shipped Today! Order within:

The TLK2 is a professional device for reusing Toyota keys. It allows for direct matching of used keys without the need to unlock. This innovative technology can significantly improve key reusability.

When a locked key is to be repurposed, the key will typically need to go through an unlocking and resetting phase. Some key models may not even be able to be refreshed due to certain encryption methods. The EoneBoss' TLK2 device was made to tackle these challenges and make keys reusable.

The TLK2 is made to be compatible with most brand or model of device without hardware limitations. It uses non-invasive technology for keys so that there would be no need to open, weld or unlock keys.

Supported Models:

  • Toyota 4A-AA BA
  • 2024+ Toyota Camry
  • 2024+ Toyota Sienna
  • 2022+ Toyota Corolla Cross
  • 2019+ Toyota Corolla
  • 2019+ Toyota Levin
  • 2016+ Toyota Allion
Call 1-800-878-6604 for Bulk / Dealer Pricing!
View full details

Details

Features:

  • Device contains light indicators to display 3 functions:
  • Green (solid): Device is connected and charging
  • Red (solid): Voice broadcast mode with real-time status updates
  • Flashing: Device is working on core operations (read, match, write)

One Main Button:

  • Power On/Off: long press of 3 seconds to toggle power
  • Status Inquiry: Short press while powered on to hear current operation via voice prompt
  • Reset: Long press of 5 seconds to reset device.



Specifications:

Manufacturer EoneBoss
Packing Dimensions  136x 78.5x17.5mm
Input Interface USB Type-C
Battery Capacity (with battery version) 3.7V, 450mAh
Wireless Frequency Band 2.4GHz and 134.2KHz
RF Transceiver High sensitivity (-94dBm@BLE)
Working Temperature -10°C~50° C
Dimensions 61.5x96.5x12.5mm
Material ABS environmental protection material
Core Chip BLE 5.0 MCU with 32-bit ARM Cortex-M4F + Cortex-M0 dual cores
Bluetooth Single-mode BLE 5.0
Input Voltage 5V DC, 500mA
Transmitter Power Up to +3 dBm
Storage Temperature -20°C~70°C



How To Use:

  • Place locked key the TLK2 sensing area and press the button so the TLK2 will begin to read the key's ID and simulate a matching key using internal data
  • Use the TLK2 device as the replacement key during vehicle pairing. The device will write key ID and other important information into the vehicle's system while also storing key related data like passwords.
  • After successful vehicle matching, the TLK2 writes the complete key information back to the original locked key so that the key can be used with the vehicle.
