Altronix - WAYPOINT3 - DC Outdoor Power Supply - Continuous Supply Current - Weather Resistant - Grey Enclosure

Altronix - WAYPOINT3 - DC Outdoor Power Supply - Continuous Supply Current - Weather Resistant - Grey Enclosure

Available to order
SKU ALT-WAYPOINT3 NSID 81100
$377.85$453.42On Sale You save $75.57 (17%)
Please Note: This product has a lead time

Altronix WayPoint3 DC Outdoor Power Supply/Charger provides 12VDC or 24VDC and is designed to be conveniently located where power is required. The lightweight molded fiberglass-reinforced polyester enclosure is NEMA 4/4X, IP66-11 rated for outdoor use and accommodates up to two (2) 12VDC/7AH batteries. It features lockable stainless steel latches and integral flanges to simplify wall or pole mounting.

Features:

  • AC and DC power LEC indicators
  • Ease of installation saves time and eliminates costly labor
  • Includes battery leads.
Call 1-800-878-6604 for Bulk / Dealer Pricing!
View full details

Details

Specifications:

Input  115VAC, 60Hz, 0.95A or 230VAC, 50Hz, 0.6A
Output
  • 12VDC or 24VDC selectable output
  • 2.5A continuous supply current
  • Filtered and electronically regulated output
  • Thermal overload and short circuit protection
Battery Charging
  • Capacity: 12VDC/7AH (1 or 2 within enclosure); Up to 40AH/65AH (Separate ventilated enclosure is required)
  • Type: Sealed lead-acid or gel type
  • Failover: Upon AC loss, instantaneous
  • (Batteries are sold separately)
Temperature
  • Operating: -40°C to 60°C (-40°F to 140°F)
  • Storage: -40°C to 70°C (-40°F to 158°F)
  • Relative Humidity: 85% +/-5%
    • BTU/Hr. (approx.):
      • 12VDC: 15 BTU/Hr.
      • 24VDC: 31 BTU/Hr.
    • System AC Input VA Requirement:
      • 115VAC: 109.25VA.
      • 230VAC: 138VA.
