The device will work only in case of a lost key. To use you just need to connect it to the OBD2 socket in the car.
PSA EMERGENCY START OBD MINI
SIEMENS, JOHNSON CONTROLS , JCI, VALEO AND CONTINENTAL BY EMERGENCY START OBD II
PSA Emergency Start / PSA Bypass Mini
PEUGEOT Citroën PSA supports all BSI down below:
BSI LIST:
- Siemens D76F0018+95160 KLINE (BSI-E0X-00/BSI-F0X-00) . EEPROM 95160
- Siemens 1L00M+95128/95256 CAN (BSI-S0X-00). EEPROM 95128/95256
- Continental SC667050+95256 CAN (BSI-Q0X-00). EEPROM 95256
- Valeo 4L00M+95128/25128 CAN (BSI2004-P0X-00).EEPROM 95128/25128
- Valeo 2M48H+24C128 CAN (BSIEV-X0X-00) . EEPROM 24C128
- Valeo SC667152+95256 CAN (BSI-N0X-00). EEPROM 95256
- Johnson Controls easyCAN4+29LV400+95128 CAN (BSI2004-H0X). EEPROM 95128
- Johnson Controls easyCAN4F1M-32+95128 CAN (BSI04EV-K0X). EEPROM 95128
- Johnson Controls SPC560B60+95128 CAN (BSI04EV2-KEX). EEPROM 95128
Supported Cars:
Here is the HTML list:
- Peugeot 1007
- Peugeot 206 (1,4 HDI, 2.0 HDI)
- Peugeot 207
- Peugeot 306 (2.0 HDI)
- Peugeot 307 (2.0 HDI)
- Peugeot 307 2005+
- Peugeot 208 2012+
- Peugeot 2008 2013+
- Peugeot 301 2012+
- Peugeot 308
- Peugeot 3008
- Peugeot 508
- Peugeot 5008
- Peugeot 406 (2.0 HDI)
- Peugeot 407
- Peugeot 607 2006+
- Peugeot 807 2006+
- Peugeot Expert II
- Peugeot Partner (2.0 HDI)
- Peugeot Ranch (2.0 HDI)
- Peugeot Partner 2008+
- Citroen C2
- Citroen C3 (1.4 HDI)
- Citroen C3 2006+
- Citroen C3 II
- Citroen DS3
- Citroen C4
- Citroen C4 Picasso
- Citroen C4 II
- Citroen DS4
- Citroen C5 (2.0 HDI)
- Citroen C5 2004+
- Citroen C5 II 2007+
- Citroen DS5
- Citroen C6
- Citroen C8 2007+
- Citroen Jumpy II
- Citroen Xsara (2.0 HDI)
- Citroen Xsara Picasso (2.0 HDI)
- Citroen Saxo (1.4 HDI)
- Citroen Berlingo (2.0 HDI)
- Citroen Berlingo 2008+
- Citroen Xantia (2.0 HDI)
- Lancia Phedra 2008+
- Citroen Picasso (2.0 HDI)
- Citroen C-Elysee 2012+
How to work with PSA Emergency OBD Mini
- To use PSA EMERGENCY START OBD MINI you just need to connect it to the OBD2 socket in the car.
- When the product is connected to OBD, the red LED (power) will stay lit. This means the power is on.
- When we plug the product into OBD, it will automatically enter PIN code reading mode for 10 seconds.
- After 10 seconds, the green LED (code) will blink fast, the PIN has been read, the product is ready. (It is waiting for you to turn on the ignition).
- When you open the contact, the green LED will stay still. (Emergency start mode is ready.)
- The car is ready to start.
- If the car is not working normally, then retry the procedure from the beginning.
PSA Emergency Start OBD Mini Led and Button Status:
- Red LED (Power)
- Green LED (Code)
- Blue LED (Can-speed mode.)
NOTE:
When the green LED (code) starts blinking, the device succesfully has read the PIN code.
When you turn the ignition on, if the car is not working, please change 500kB/s can-speed to 250kB/s by pressing the button on the device. (Blue LED)
