Alarm Lock Trilogy - PDL1300ETNW - Narrow-Stile Digital PROX Keypad Lever Lock Exit Trim - Networx - Audit Trail - 26D - Satin Chrome
Get it shipped ! Order within:
Get it shipped ! Order within:
Get an Extra Hour with
- $747.01
-
$870.29 - $747.01
- Translation missing: en.products.product.selected_or_first_available_variant.price.unit_price
- per
The Trilogy PDL1300ETNW-26D - Networx Narrow-Stile Digital Networx PROX Lever Lock Exit Trim - 2000 Users - 40,000 Event Audit Trail - Satin Chrome
Trilogy Narrow Stile Keypad Lever Lock w/ Audit Trail supports Adams Rite® latch. products. Get field-proven Trilogy® keyless access lock convenience anywhere there's a Narrow Stile compatible door. Weatherproof, all-metal, and vandal-resistant, they offer automatic lock or free passage schedules to Adams Rite® latch applications, emergency global lockdown in seconds, and have unsurpassed battery life. The DL1300 series is a rugged entry lock of advanced design with several programmable features.
- Built-in Proximity Reader: Easy Tap & Add batch prox ID card enrollment mode allows many cards to be quickly added without PC –also– downloadable from PC or prox enroller tool
- Features Alarm Locks Networx connectivity so you can communicate with up to 63 different locks via a gateway connection
- Include a mortise cylinder that has 2 keys included
- More Information Below
SPECIFICATIONS:
| LOCK FUNCTION | Entrance Narrow-Stile PROX Keypad Lever Lock w/ Audit Trail |
| DOOR THICKNESS | Only Stile thickness 1 ¾" |
| BACKSET | 3 1/32”,1 1/8’ and 1 1/2” |
| HANDING | Non-handed; fully field-reversible |
| LEVER TRIM | Leverset compatible with Adams Rite 4500, 4700 & 4900 series deadlatch |
| POWER | Long-life, battery-operated for 80,000 to 100,000 Cycles respectively, typical on two 3-Volt 123A Lithium batteries, supplied; low battery alert |
| CYLINDER | 6-pin standard mortise cylinder in SC1 Keyway supplied (Supports 1-1/2" 1-3/8”) |
| KEYS | 2 Keys Included |
| CAMS | Cams supplied works with generic Alarm Lock cylinder |
| PROGRAMMABLE | Yes |
| USER CODES | support 2000 users by PIN, HID Prox ID cards, or fobs. PC programming/reporting and features 40,000 events audit trail by the user and 500 events schedule/real-time clock (e.g. lock/unlock by time) |
| PROXIMITY FREQUENCY | 125 kHz |
| GATEWAYS & COMPATIBILITY | Choice of networking options for any application, control 63 locks per Gateway and 2016 Locks per system. Compatible with AL-IME2, AL-IME2-80211, AL-IME2-POE |
| SOFTWARE | Free Windows-based software for programming, entering users, and receiving time-/date-stamped (by user) 35K event audit trail from the lock. |
| Audit Trail | 40,000 Event |
| WEATHERPROOF | -31˚ to +151˚F (-35˚ to +66˚C) |
| CONSTRUCTION | Zinc Alloy, Vandal Resistant |
| FINISH | Satin Chrome |
